Thông số kỹ thuật
|
Item |
Parameter |
Remark |
|
|
Basic Parameter |
|||
|
Pixel Pitch |
1.875mm |
1.875mm |
|
|
Pixel Structure |
3IN1 SMD |
3IN1 SMD |
|
|
Pixel Density |
284444pixels/m2 |
284444pixels/m2 |
|
|
Module Resolution |
128X128 |
160×90 |
|
|
Module Size(WxHxD) |
240x240mm |
300×168.75 |
|
|
Module Weight(kg) |
0.5 |
0.5 |
|
|
Optical Parameter |
|||
|
Single Point Brightness,Chroma Correction |
support |
support |
|
|
White Balance Brightness |
≥600cd/㎡ |
≥600cd/㎡ |
|
|
Color Temperature |
2000K—12500KAdjustable |
2000K—12500KAdjustable |
|
|
Horizontal Viewing Angle |
160Deg. |
160Deg. |
|
|
Vertical Viewing Angle |
140Deg. |
140Deg. |
|
|
Visible Distance |
4+ m |
4+ m |
|
|
Brightness Uniformity |
≥97% |
≥97% |
|
|
Contrast Ratio |
≥5000:1 |
≥5000:1 |
|
|
Process Performance |
|||
|
Signal processing bits |
16bits*3 |
16bits*3 |
|
|
Gray scale |
12-16Bit |
12-16Bit |
|
|
Control Distance |
Cable: 100 m,Optical Fiber:10km |
Cable: 100 m,Optical Fiber:10km |
|
|
Drive Mode |
constant current source driver |
constant current source driver |
|
|
Frame Rate |
≥60HZ |
≥60HZ |
|
|
Refresh Rate |
1920-3840HZ |
1920-3840HZ |
|
|
Way to Control |
Synchronize |
Synchronize |
|
|
Brightness Adjustment Range |
0-100Stepless Adjustmen |
0-100Stepless Adjustmen |
|
|
Usage Parameter |
|||
|
Continuous Operation Time |
≥72h |
≥72h |
|
|
Expected LED Lifetime(Max) |
>100,000 hours |
>100,000 hours |
|
|
IP Rating |
IP20 |
IP20 |
|
|
Operating Temperature |
-20 ℃ to 50 ℃ |
-20 ℃ to 50 ℃ |
|
|
Operating Humidity |
10 %- 80% RH No Condensation |
10 %- 80% RH No Condensation |
|
|
Storage Temperature |
-20 ℃ to 60 ℃ |
-20 ℃ to 60 ℃ |
|
|
Electrical Parameter |
|||
|
Operating Voltage |
DC4.5-5V |
DC4.5-5V |
|
|
Power Requirements |
AC:220×(1±10%)V、50×(1±5%)Hz |
AC:220×(1±10%)V、50×(1±5%)Hz |
|
|
Maximum power consumption |
650W/㎡ |
650W/㎡ |
|
|
Average power consumption |
270W/㎡ |
270W/㎡ |
|
